LC150

Specifications:

• Max Dimensions: 6 x 4m
• Max Blind Width: 4m (Including Beam)
• Maximum Span Without Post: 6 x 4 no middle beam
• Color: Black, White, Charcoal, Custom (RAL)
• Material: AKZO Powder Coated Aluminium
• Aluminium Grade: 6063-T6
• Post: 150 x 150 x 2.0-3.0mm
• Beam With Gutter: 200 x 123 x 3.0mm

• Blade: 193 x 40 x 1.6-1.7mm
• Motor: Grade IP67
• Light: 3000K Warm Light + 6000K White Light (Stepless Dimming)
• Tilt Range: 0-110 Degrees
• Wind Resistance: 169km/h
• Snow Load: 178kg/m² (60cm thickness)
• Warranty: 10 years on structures and 3 years on motors
